Applications
Portable Hand Tools, Welder Guns, Spray guns, Short Blast Guns, Drifting Attachments in mines and Quarries, Jute and synthetic bag closing machines, Gauges, Jigs and Fixtures, Pendant Station, Switch Button of Hoists, incase of de-oxidation, water washing of plating work with raising and lowering of work etc.

Home | Site Map | Customer Info | About Us
Design
SAPSONS Overhead Spring Balancers are specially designed to free the operator from weight of the hand tools. When properly balanced by adjusting spring tension, the tools become almost weightless in the hands of the operator, and can be moved up and down with very little effort.
Advantages
A.) Increases Productivity - Balancers keep poised for action, minimize motions required to bring tool from rest to work positions. Extends Tool Life Balancers eliminate pick-up and lay down wear and prevent damage from dropping.
B.) Reduces Operator Fatigue - A Balancer makes the heaviest tool light as a feather. Operator effort can be directed to controlling the tool rather than supporting.
C.) No Need of Power - There is no need of electrical or mechanical power.
D.) Increases Safety - Balancers keep work area uncluttered to reduce chances of damages of accessories or accidental start up of tools during handling.
E.) Effective Use of Space - The working place being widely utilized, and also to be cleaned up, the production is smoothly carried out.

SPECIFICATIONS
Model No. Balancing Capacity Travel in Mtr.

Rope

Dia (MM)

Unit Weight

Kgs.

Min. Kgs. Max.Kgs
ECB-1 0.25 1.5 1.0 3.0 1.2
ECB-2 1.0 2.0 1.0 3.0 1.2
ECB-3 1.0 3.0 1.3 3.5 2.3
ECB-5 2.5 5.0 1.3 3.5 2.3
ECB-9 4.5 9.0 1.3 4.0 4.2
ECB-15 9.0 15.0 1.3 4.0 4.5
ECB-22 15.0 22.0 1.5 5.0 9.0
ECB-30 22.0 30.0 1.5 5.0 9.5
ECB-40 30.0 40.0 1.5 5.0 10.5
ECB-50 40.0 50.0 1.5 5.0 11.2
ECB-60 50.0 60.0 1.5 5.0 12.6
ECB-70 60.0 70.0 1.5 5.0 13.6
ECB-85 70.0 85.0 1.5 6.0 16.0
ECB-100 85.0 100.0 1.5 6.0 19.0
ECB-120 100.0 120.0 1.5 6.0 20.5
ECB-140 120.0 140.0 1.8 6.0 -
ECB-170 140.0 170.0 1.8 6.0 -
ECB-200 170.0 200.0 1.8 6.0 -
